RB1100x4 : Powerful 1U rackmount router with 13x Gigabit Ethernet ports ,RouterOS L6
คุณสมบัติสินค้า:
[ RB1100x4 ] รีวิว จำหน่าย ราคา Mikrotik RouterBoard รุ่นที่มาพร้อมกับ 13x GbE RJ45 , 4 Core 1.4 GHz CPU ทำงานบนระบบปฎิบัติการ RouterOS L6
หมวดหมู่ : Mikrotik , Ethernet Router ,
แบรนด์ : Mikrotik
รายละเอียดสินค้า
Test Results
Datasheet / Downloads
| Specifications | |
| Product code | RB1100x4 |
| Architecture | ARM 32bit |
| CPU | AL21400 |
| CPU core count | 4 |
| CPU nominal frequency | 1.4 GHz |
| Dimensions | 443 x 148 x 44 mm |
| RouterOS license | 6 |
| Operating System | RouterOS |
| Size of RAM | 1 GB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| IPsec hardware acceleration | Yes |
| Powering | |
| Number of AC inputs | 2 |
| AC input range | 100-240 |
| Number of DC inputs | 2 (2-pin terminal, PoE-IN) |
| 2-pin terminal input Voltage | -48, 12-57 V |
| Max power consumption | 20 W |
| Cooling type | Passive |
| PoE in | 802.3af/at |
| PoE in input Voltage | 20-57 V |
| Ethernet | |
| 10/100/1000 Ethernet ports | 13 |
| Peripherals | |
| Memory card type | microSD |
| Memory Cards | 1 |
| Serial console port | RS232 |
| Other | |
| Current Monitor | Yes |
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Mode button | Yes |
| Beeper | Yes |
| Certification & Approvals | |
| Certification | CE, EAC, ROHS |
| IP | IP20 |
