Mikrotik Multifunction Router ที่จะช่วยให้การทำงานของคุณ ราบรื่น ด้วยอุปกรณ์เพียงชิ้นเดียว
ขอต้อนรับทุกท่านเข้าสู่โลกแห่ง Mikrotik Network สำหรับรีวิวนี่จะพาทุกท่านไปรู้จักกับ Mikrotik Wireless Router รุ่น hAP ac lite [ RBcAP2nD ]
Product Code : RBcAP2nD
มีอะไรอยู่ใน Mikrotik Router รุ่น hAP ac lite
hAP ac lite เป็น Wireless Access Point ชนิด Dual Band Dual-Chain รองรับมาตรฐานการเชื่อมต่อแบบ WiFi 4 และ WiFi 5 สามารถทำงานได้ 2 คลื่นความถี่ในเวลาเดียวกันได้ในย่าน 2.4GHz และ 5GHz
Spec ของตัวเครื่อง hAP ac lite จะประกอบไปด้วยหน่วยประมวลซีพียู 650MHz, RAM 64MB, Ethernet Port ชนิด 10 / 100Mbps จำนวน 5 Port นอกจากนี้แล้ว hAP ac lite ยังสามารถจ่ายไฟออกไปเลี้ยงอุปกรณ์อื่นๆ จาก Port 5 ได้อีกด้วย นั่นก็หมายความว่า ETH 5 ทำหน้าที่เป็น PoE Output นั่นเอง
hAP ac lite ยังมี Port USB สำหรับเชื่อมต่อกับ Modem 3G/4G ทำงานภายใต้ระบบปฎิบัติการ RouterOS L4
ข้อควรปฎิบัติเมื่อเริ่มต้นใช้งาน Mikrotik
แนวทางการเลือกซื้อ
( ตาราง 1 ) ระบบฎิบัติการ RouterOS ของ Mikrotik นั้น เขาจะแบ่ง License ออกเป็นหลาย Level ดังต่อไปนี้
Level Number | 0 ( Trial Mode ) | 1 ( Free Demo ) | 3 ( WISP CPE ) | 4 ( WISP ) | 5 ( WISP ) | 6 Controller |
Wireless AP | 24H Trial | - | - | Yes | Yes | Yes |
Wireless Client and Bridge | 24H Trial | - | Yes | Yes | Yes | Yes |
RIP,OSPF,BGP Protocols | 24H Trial | - | Yes | Yes | Yes | Yes |
Eoip Tunnels | 24H Trial | 1 | Unlimited | Unlimited | Unlimited | Unlimited |
PPPoE Tunnels | 24H Trial | 1 | 200 | 200 | 500 | Unlimited |
PPTP Tunnels | 24H Trial | 1 | 200 | 200 | 500 | Unlimited |
L2TP Tunnels | 24H Trial | 1 | 200 | 200 | 500 | Unlimited |
OVPN Tunnels | 24H Trial | 1 | 200 | 200 | Unlimited | Unlimited |
VLAN Interface | 24H Trial | 1 | Unlimited | Unlimited | Unlimited | Unlimited |
Hotspot Active Users | 24H Trial | 1 | 1 | 200 | 500 | Unlimited |
Radius Client | 24H Trial | - | Yes | Yes | Yes | Yes |
Queues | 24H Trial | 1 | Unlimited | Unlimited | Unlimited | Unlimited |
Web Proxy | 24H Trial | - | Yes | Yes | Yes | Yes |
User Manager Active Sessions | 24H Trial | 1 | 10 | 20 | 50 | Unlimited |
Number Of VPN Guest | None | 1 | Unlimited | Unlimited | Unlimited | Unlimited |
Mirktoik RouterOs Main features
• 802.11a/b/g/n/ac support
• Custom Nv2 TDMA protocol
• Advanced Quality of Service
• Stateful firewall, tunnels
• STP bridging with filtering
• WDS and Virtual AP
• HotSpot for Plug-and-Play access
• RIP, OSPF, BGP, MPLS routing
• Remote WinBox GUI and Web admin
• High availability with VRRP
• Bonding of Interfaces
• Telnet/mac-telnet/ssh/console admin
• Real-time configuration and monitoring
• 3G/LTE support
• OpenFlow support
คุณสมบัติจำเพาะ
Product code | RBcAP2nD |
Architecture | MIPSBE |
CPU | QCA9533 |
CPU core count | 1 |
CPU nominal frequency | 650 MHz |
Dimensions | 185mm diameter, 31mm height |
Operating System | RouterOS |
RouterOS license | 4 |
Size of RAM | 64 MB |
Storage size | 16 MB |
Storage type | FLASH |
MTBF | Approximately 100'000 hours at 25C |
Tested ambient temperature | -40°C to 60°C |
IPsec hardware acceleration | Yes |
Wireless capabilities
Wireless 2.4 GHz Max data rate | 300 Mbit/s |
Wireless 2.4 GHz number of chains | 2 |
Wireless 2.4 GHz standards | 802.11b/g/n |
Antenna gain dBi for 2.4 GHz | 2 |
Wireless 2.4 GHz chip model | QCA9533 |
Wireless 2.4 GHz generation | Wi-Fi 4 |
Ethernet
Detail | |
10/100 Ethernet ports | 1 |
Powering
Number of DC inputs | 1 (PoE-IN) |
Max power consumption | 4 W |
FAN count | Passive |
PoE in | 802.3af/at |
PoE in input Voltage | 11-57 V |
Certification & Approvals
Detail | |
Certification | CE, FCC, IC, EAC, ROHS |
IP | IP20 |
Wireless specifications
2.4 GHz | Transmit (dBm) | Receive Sensitivity |
1MBit/s | 22 | -96 |
11MBit/s | 22 | -89 |
6MBit/s | 20 | -93 |
54MBit/s | 18 | -74 |
MCS0 | 20 | -93 |
MCS7 | 16 | -71 |
สิ่งที่มีมาให้ในกล่อง
Ethernet test results
RBcAP2nD | QCA9533 100M one port test | ||||||
Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
Bridging | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 173.6 | 88.9 |
Bridging | 25 bridge filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 82.2 | 42.1 |
Routing | none (fast path) | 8.1 | 98.4 | 23.5 | 96.3 | 160.8 | 82.3 |
Routing | 25 simple queues | 8.1 | 98.4 | 23.5 | 96.3 | 118.7 | 60.8 |
Routing | 25 ip filter rules | 8.1 | 98.4 | 23.5 | 96.3 | 53.9 | 27.6 |
1. การทดสอบทั้งหมดทำด้วยอุปกรณ์ทดสอบเฉพาะของ Xena Networks (XenaBay) และทำตาม RFC2544 (Xena2544)
2. ปริมาณ Throughput ถูกกำหนดด้วยความพยายาม 30+ วินาทีโดยมีค่าเผื่อการสูญเสียแพ็กเก็ต 0,1% ในขนาดแพ็คเก็ต 64, 512, 1518 ไบต์
3. ผลการทดสอบแสดงประสิทธิภาพสูงสุดของอุปกรณ์และเมื่อถึงโดยใช้การกำหนดค่าฮาร์ดแวร์และซอฟต์แวร์ดังกล่าวการกำหนดค่าที่แตกต่างกันมักจะส่งผลให้ผลลัพธ์ลดลง
